    Steel Materials Hydraulic Tailgate Lift With 10L Oil Cylinder 1000kg

    Ask Lasest Price
    Brand Name : leeo
    Model Number : LA-10-135
    Certification : CE
    Price : $2000---$5000/unit
    Supply Ability : 200 units/ per Month
    Delivery Time : 10-20 work days
    • Product Details
    • Company Profile

    Steel Materials Hydraulic Tailgate Lift With 10L Oil Cylinder 1000kg

    High quality hydraulic power tailgate lift light truck car tail lift for sales


    Product Description

    BrandLEEO
    Load Rated1000 KG
    Max Lift Height1350 MM
    Platform MaterialSteel or Aluminum Alloy
    Platform Dimension (Width* height)2200 * 1800 MM(also can do customized)
    Platform Weight420-535 KG(depends on material)
    Operating VoltageDC24V
    Power2KW
    Lift Speed60-90mm/s(adjustable)
    System Pressure18MPa

    What does a tail lift do?

    A tail lift (term used in the UK, also called a "liftgate" in North America) is a mechanical device permanently installed on the rear of a work truck, van, or lorry, and is designed to facilitate the materials handling of goods from ground level or a loading dock to the level of the vehicle bed, or vice versa.

    Steel Materials Hydraulic Tailgate Lift With 10L Oil Cylinder 1000kg


    Hydraulic cylinderSelected American PAKER, MPI low temperature resistant sealing ring, the piston rod is plated with hard chromium, the cylinder barrel is super-precisely ground, two multi-combination sealing structure, the performance is more stable. The cylinder is equipped with a sleeve-type sheath, which is beautiful in appearance and durable.

    Why Choose US


    A>Our products have a high technical starting point: they are at the highest level in China, and a large number of products are exported to Hong Kong.

    B> Our product hydraulic system selects European well-known brands—HALDEX, PAKER.MPI to ensure quality

    C> Our Philosophy is: Active service, Pursuit of perfection

    D> We are a professional team composed of professionals in the automotive tailboard industry at home and abroad; we are proficient in products, understand customers, put people first, and pursue excellence.

    Steel Materials Hydraulic Tailgate Lift With 10L Oil Cylinder 1000kg


    Main Products Parameter


    Model NoLoad capacity (KG)Height from Ground to Carriage (MM)Platform Dimension (W*H) MMOperating Voltage (V)Lifting Speed (CM/S)Total weight (KG)
    SteelAluminum Alloy
    LA-7-90700800-9001600*1700126-9320260
    LA-10-1201000950-12001800*170012/246-9390290
    LA-15-1201500950-12002000*170012/246-9450330
    LA-15-13515001050-13502200*1800246-9490370
    LA-15-15215001150-15202300*1800246-9550430
    LA-20-13520001050-13502400*1800246-9520410
    LA-20-15220001150-15202400*1800246-9580460
    LA-25-15225001150-15202400*1800246-9630490
    LA-25-16025001150-16002400*1800246-9750590

    Company Profile

    Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.


    Steel Materials Hydraulic Tailgate Lift With 10L Oil Cylinder 1000kg


    FAQ


    Q:HOW AHOUT THE DELIVERY TIME?

    A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.


    Q:HOW ABOUT THE PAYMENT?

    A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.


    Q: HOW LONG IS THE WARRANTY TIME?

    A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST.


    Q:HOW TO DELIVERY THE GOODS.

    A: BY SEA OR BY RAILWAY.


    Q: WHAT ABOUT THE AFTER-SALE SERVICE?

    A: IF THERE ANY QUALOTY ISSUE, PLEASE SEND US THE PHOTOS OR VIDEO,WE WILL OFFER THE SOLUTION WITHIN 24 HOURS.
