    Steel Platform Hydraulic Tail Lift For Truck Van 12V 2KW

    Ask Lasest Price
    Brand Name : LEEO
    Model Number : LA-15-120
    Certification : CE
    Price : $2000---$5000/unit
    Supply Ability : 200 units/ per Month
    Delivery Time : 10-20 work days
    Payment Terms : T/T
    • Product Details
    • Company Profile

    Steel Platform Hydraulic Tail Lift For Truck Van 12V 2KW

    Cantilever Hydraulic Tail Lift On The Rear Of The Steel Platform For Refrigerated Trucks

    Product Description
    Platform Weight390-515 KG(depends on material)
    Operating VoltageDC24V
    Power2KW
    Lift Speed

    60-90mm/s(adjustable)

    Max Lift Height1520 MM
    Platform MaterialSteel or Aluminum Alloy
    Platform Dimension (Width* height)2300 * 1800 MM(also can do customized)
    Load Rated1500 KG

    Keeping in mind the growing demand of the logistics sector for fast, easy and efficient deliveries, LEEO’s Column Tail Lift is specially designed for Medium & Large Commercial vehicles from 4 to 12 Ton GVW offering lifting capacity from 1000 kg to 2000 kg.

    Steel Platform Hydraulic Tail Lift For Truck Van 12V 2KW

    A hydraulic tailgate lift or rear lift is a hinged flap at the rear of the vehicle that moves up and down to load and unload any material in the vehicle. In short, the tailgate or rear lift is a large and heavy piece of equipment that adds to the overall vehicle weight. The hydraulic tailgate lift is operated by the driver or co-pilot of the vehicle. Standard tailgates use hydraulics to push a piston through an air cylinder, moving the door up and down. The movement of the gate is controlled with the help of a switch box with up and down functions. The hydraulic rear lift is produced first with all components ready to be installed on the vehicle. It takes a few days to install the tailgate on the vehicle. The hydraulic tailgate is designed according to the vehicle's space.


    Main Products Parameter


    Model NoLoad capacity (KG)Height from Ground to Carriage (MM)Platform Dimension (W*H) MMOperating Voltage (V)Lifting Speed (CM/S)Total weight (KG)
    SteelAluminum Alloy
    LA-7-90700800-9001600*1700126-9320260
    LA-10-1201000950-12001800*170012/246-9390290
    LA-15-1201500950-12002000*170012/246-9450330
    LA-15-13515001050-13502200*1800246-9490370
    LA-15-15215001150-15202300*1800246-9550430
    LA-20-13520001050-13502400*1800246-9520410
    LA-20-15220001150-15202400*1800246-9580460
    LA-25-15225001150-15202400*1800246-9630490
    LA-25-16025001150-16002400*1800246-9750590

    Company Profile

    Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.


    Steel Platform Hydraulic Tail Lift For Truck Van 12V 2KW


    FAQ


    Q: WHAT ABOUT THE AFTER-SALE SERVICE?

    A: IF THERE ANY QUALOTY ISSUE, PLEASE SEND US THE PHOTOS OR VIDEO,WE WILL OFFER THE SOLUTION WITHIN 24 HOURS.


    Q:HOW AHOUT THE DELIVERY TIME?

    A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.


    Q:HOW ABOUT THE PAYMENT?

    A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.


    Q: HOW LONG IS THE WARRANTY TIME?

    A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST

    Steel Platform Hydraulic Tail Lift For Truck Van 12V 2KW


    Welcome to inquire!

    Looking for the agents!
