Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate

XI'an Leeo Hydraulic Equipment Limited Company
Contact Now
    Buy cheap Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate from wholesalers

    Buy cheap Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate from wholesalers
    • Buy cheap Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate from wholesalers
    • Buy cheap Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate from wholesalers

    Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate

    Ask Lasest Price
    Brand Name : LEEO
    Model Number : LA-15-152
    Supply Ability : 200 units/ per Month
    Price : $2000---$5000/unit
    Certification : CE
    Delivery Time : 10-20 work days
    Payment Terms : T/T
    • Product Details
    • Company Profile

    Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate

    Durable Long Life Truck Parts Of Vehicle Tail Lift With Hydraulic Power For Sales

    Product Description

    Power: 2KW

    Voltage: DC24V

    Platfrom Material: Steel or Aluminum

    Max lift height: 1520 MM

    Platform Dimension(W*H) 2300*1800 MM

    Weight: 420--535 Kg

    Lift speed: 60--90 mm/s

    System Pressure: 18Mpa

    Load Capacity: 1500 Kg


    Advantage


    Using a tail lift can make it unnecessary to use machinery such as a forklift truck to load heavy items on to a vehicle. A tail lift can also bridge the difference in height between a loading dock and the vehicle load bed.


    The majority of tail lifts are hydraulic or pneumatic in operation, although they can be mechanical, and are controlled by an operator using an electric relay switch.


    Main Products Parameter


    Model NoLoad capacity (KG)Height from Ground to Carriage (MM)Platform Dimension (W*H) MMOperating Voltage (V)Lifting Speed (CM/S)Total weight (KG)
    SteelAluminum Alloy
    LA-7-90700800-9001600*1700126-9320260
    LA-10-1201000950-12001800*170012/246-9390290
    LA-15-1201500950-12002000*170012/246-9450330
    LA-15-13515001050-13502200*1800246-9490370
    LA-15-15215001150-15202300*1800246-9550430
    LA-20-13520001050-13502400*1800246-9520410
    LA-20-15220001150-15202400*1800246-9580460
    LA-25-15225001150-15202400*1800246-9630490
    LA-25-16025001150-16002400*1800246-9750590

    Company Profile

    Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.


    Durable 1500Kg Vehicle Tail Lift 2.3m Hydraulic Box Truck Lift Gate


    FAQ


    Q: WHAT ABOUT THE AFTER-SALE SERVICE?

    A: IF THERE ANY QUALOTY ISSUE, PLEASE SEND US THE PHOTOS OR VIDEO,WE WILL OFFER THE SOLUTION WITHIN 24 HOURS.


    Q:HOW ABOUT THE PAYMENT?

    A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.


    Q:HOW AHOUT THE DELIVERY TIME?

    A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.


    Q: HOW LONG IS THE WARRANTY TIME?

    A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST.
