Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate

XI'an Leeo Hydraulic Equipment Limited Company
Contact Now
    Buy cheap Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate from wholesalers

    Buy cheap Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate from wholesalers
    • Buy cheap Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate from wholesalers
    • Buy cheap Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate from wholesalers

    Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate

    Ask Lasest Price
    Brand Name : Leeo
    Certification : CE
    Supply Ability : 200 units/ per Month
    Price : $2000---$5000/unit
    Model Number : LA-15-135
    Delivery Time : 10-20 work days
    • Product Details
    • Company Profile

    Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate

    New Truck Tail Lift Vehicle Tail Lift Made In China For Sales

    Product Description

    Load Capacity: 1500KG

    Max Lift Height:1350MM

    Platform Material: Steel or Aluminum alloy

    Platform Dimension (Standard size: Width * Height) 2200 *1800 MM (also can do customized)

    Weight (KG): Steel 550/Aluminum Alloy 400

    Operating Voltage:DC24V

    Power:2.5KW

    System Pressure:18Mpa


    What is a hydraulic tailgate?


    A Liftgate, which can also be referred to as a Tail lift, is a mechanical device which is installed permanently at the back or the rear end of a large vehicle like a truck, a lorry or a van. It is used to load and unload freight from the ground and into the back of the truck.


    The majority of tail lifts are hydraulic or pneumatic in operation, although they can be mechanical, and are controlled by an operator using an electric relay switch.


    Tail lifts make it easier to safely load and unload trucks and can help for save labor cost and improve the working efficiency.


    Why Choose US


    A>Our products have a high technical starting point: they are at the highest level in China.


    B> Our product hydraulic system selects European well-known brands—HALDEX, PAKER.MPI to ensure quality


    C> We are a professional team and we are proficient in products, understand customers, put people first, and pursue excellence.


    Main Products Parameter


    Model NoLoad capacity (KG)Height from Ground to Carriage (MM)Platform Dimension (W*H) MMOperating Voltage (V)Lifting Speed (CM/S)Total weight (KG)
    SteelAluminum Alloy
    LA-7-90700800-9001600*1700126-9320260
    LA-10-1201000950-12001800*170012/246-9390290
    LA-15-1201500950-12002000*170012/246-9450330
    LA-15-13515001050-13502200*1800246-9490370
    LA-15-15215001150-15202300*1800246-9550430
    LA-20-13520001050-13502400*1800246-9520410
    LA-20-15220001150-15202400*1800246-9580460
    LA-25-15225001150-15202400*1800246-9630490
    LA-25-16025001150-16002400*1800246-9750590

    Company Profile

    Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.


    Customized Color 1700mm Truck Lift Gates 700kg Tractor Trailer Liftgate


    FAQ


    Q:HOW AHOUT THE DELIVERY TIME?

    A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.


    Q:HOW ABOUT THE PAYMENT?

    A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.


    Q: HOW LONG IS THE WARRANTY TIME?

    A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST.


    Q: WHAT ABOUT THE AFTER-SALE SERVICE?

    A: IF THERE ANY QUALOTY ISSUE, PLEASE SEND US THE PHOTOS OR VIDEO,WE WILL OFFER THE SOLUTION WITHIN 24 HOURS.
