    JieFang Truck Lift Gate 2000*1800mm Hydraulic Lift End Gate

    Ask Lasest Price
    Brand Name : leeo
    Model Number : LA-10-120
    Supply Ability : 200 units/ per Month
    Price : $2000---$5000/unit
    Certification : CE
    Delivery Time : 10-20 work days
    Payment Terms : T/T
    • Product Details
    • Company Profile

    JieFang Truck Lift Gate 2000*1800mm Hydraulic Lift End Gate

    Low MOQ Truck Parts Hydraulic Tailgate Truck Lift Gate For Sale


    Product Description

    Weight (KG): Steel 440/Aluminum Alloy 320

    Operating Voltage:DC12V/24V (depends on the vehicle voltage)

    Power:2.5KW

    System Pressure:18Mpa

    Lift Speed:60-90mm/s (adjustable speed)

    Main cable: National standard YH-25mm²/8.5m

    Load Capacity: 500-1000KG

    Max Lift Height:1200MM

    Platform Material: Steel or Aluminum alloy

    Platform Dimension (Standard size: Width * Height) 2000 *1800 MM (also can do customized)


    Hydraulic piping systemThe five-cylinders, hydraulic automatic leveling, the use of a shunt valve plate, reduce joints, reduce leakage hazards, and increase safety valves to ensure safer system operation and avoid accidents. The hydraulic hose is made of double-layer steel wire rubber tube, which is resistant to wear, high pressure and aging.

    Tail lifts make it much easier to safely load and unload trucks and are synonymous with cost efficiency, flexibility and a high level of operating comfort for users.


    Using a tail lift can make it unnecessary to use machinery such as a forklift truck to load heavy items on to a vehicle. A tail lift can also bridge the difference in height between a loading dock and the vehicle load bed.


    Why Choose US


    A>We are a professional team and we are proficient in products, understand customers, put people first, and pursue excellence.


    B>Our products have a high technical starting point: they are at the highest level in China, and a large number of products are exported to Hong Kong.


    C> Our Philosophy is: Active service, Pursuit of perfection


    D> Our product hydraulic system selects European well-known brands—HALDEX, PAKER.MPI to ensure quality.


    Main Products Parameter


    Model NoLoad capacity (KG)Height from Ground to Carriage (MM)Platform Dimension (W*H) MMOperating Voltage (V)Lifting Speed (CM/S)Total weight (KG)
    SteelAluminum Alloy
    LA-7-90700800-9001600*1700126-9320260
    LA-10-1201000950-12001800*170012/246-9390290
    LA-15-1201500950-12002000*170012/246-9450330
    LA-15-13515001050-13502200*1800246-9490370
    LA-15-15215001150-15202300*1800246-9550430
    LA-20-13520001050-13502400*1800246-9520410
    LA-20-15220001150-15202400*1800246-9580460
    LA-25-15225001150-15202400*1800246-9630490
    LA-25-16025001150-16002400*1800246-9750590

    Company Profile

    Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.


    JieFang Truck Lift Gate 2000*1800mm Hydraulic Lift End Gate


    FAQ


    Q: WHAT ABOUT THE AFTER-SALE SERVICE?

    A: IF THERE ANY QUALOTY ISSUE, PLEASE SEND US THE PHOTOS OR VIDEO,WE WILL OFFER THE SOLUTION WITHIN 24 HOURS.


    Q:HOW AHOUT THE DELIVERY TIME?

    A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.


    Q: HOW LONG IS THE WARRANTY TIME?

    A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST.


    Q:HOW ABOUT THE PAYMENT?

    A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.
